solar cells

ltd.

photovoltaic cell manufacturer



Since 1987, Solar cells have offered the benefits of photovoltaic modules and plates under trade mark "Microex" - New generation at an affordable price.
Solar cells creates no dangeours waste products.
Solar cells are infinitely renewable and inexhaustible"
solar energy is clean and reliable.
It is non-polluting and environmentally benign.
Solar cells provide an attractive,maintenance-free method to generate electricity reliably.

Put the Power of the Sun to Work for You

These solar cells are constructed from standard photovoltaic product which is an amorphous thin silicon device deposited on a glass substrate.For long-term reliability, we implement a unique process of fully protecting the sillicon layer of solar cells with an additional glass backing;resulted in a 'sandwiched' solar cell encapsulation within glass and UV resin.Solar cells are framed by a polycarbonate extrusion,sealing and protecting the glass edges.This solar cells shall be framed with aluminium profile prepared for fastening on the surface.
Within EPIA - the European Photovoltaic Industry Association-solar energy is not regarded just as an alternative to convertional energy sources.It is regarded as having the potential of becoming the ultimate solution to mankind's energy problem.
MICROEX
Microex solar cells are designed for a variety of applications including utillity interactive power systems,stand-alone generating systems and many small power generating applications.
We use our own Research and Development Laboratories to further our work in this area in cooperation with Institute Rudjer Boskovic in Zagreb.
Explanations & definitions
* Plate product shall be defined as a photovoltaic device on a glass substrate protected with a roller coated film medium
* Modules shall be defined as a photovoltaic device on a glass substrate protected with a glass - to -glass,edge seal and frame encapsulating system.All modules shall be framed with black plastic framing material or aluminium frame.
* The standard test conditions (STC) shall be defined as Insolation = 1000 W/m2,Module Temperature = 25 degrees Centigrade, Air Mass = 1.5 and Wind Speed = (TBA)
* The short circuit current,Isc,is defined as the current when there is no voltage across the load at STC.
* To open circuit voltage,Voc is defined as the voltage when no current is being drawn at STC.
* The specified voltage,Vspec,is the voltage at which the circuit is designed to draw current from the PV device.
* The peak wattage is defined as the product of current and voltage at the peak power point;that is,Wpeak = I peak x V peak at STC
* The System Voltage Max shall be defined as the maximum voltage that a module or plate should be subjected to when connected into a series string -600 V

Solar cells Features

:
* Available in plate or modules form
* Microthin Film Technology
* Double-Glass Lamination for Maximum Life
* Anodized Aluminium or Polycarbonate Frame Seals and Protect Glass
* Available in wide range sizes from 1.15 to 14.00 Watts
* Superior Performance in Partial Shade Conditions
* 6-Year Warranty on Workmanship and Power Output
* Connections are made trough a polarized plug-in connector
* Modules are supplied with the mating connector
* Frame is made of anodized aluminium and contains a groove in which an M6 bolt head can be inserted.

Solar cells - Quality assurance


* Thermal cycling test
* Thermal shock test
* Thermal/Freezing and high humidity cycling test
* Hall impact test
* Mechanical ,wind and twist loading test
* Salt mist test
* Light and water-exposure test

Solar cells - Environmental conditions


Operating temperature -40 +90' C

Solar cells - Commercial conditions

:
* EX WORKS
* BULK PACKAGE
* PACKAGE IN CARTON BOXES
* PREPARED FOR TRUCK OR CONTAINER TRANSPORTATION
* MINIMUM ORDER'S :
- FOR MODULES MORE THEN 500 PCS.
- FOR PLATES MORE THEN 2000 PCS.
FOR SPECIAL ADDITIONAL REQUEST - PLEASE CALL US !

Production of amorphous "MICROEX" Thin Film Silicon modules & plates are consist of the following production steps (SIMPLIFIED).
1.TIN OXIDE DEPOSITION
2.TIN OXIDE LASER PATTERNING
3.AMORPHOUS SILICON DEPOSITION
4.SILICON GREEN LASER PATTERNING
5.ALUMINIUM DEPOSITION
6.ALUMINUM PATTERNING
7.GLASS TO GLASS ENCAPSULATION
8.LIGHT TESTING #1
9.HEAT AGING
10.LIGHT TESTING #2
11FRAMING
12.LIGHT TESTING #3
QUALITY ASSURANCE ACCORDING TO ISO9002
Solar cells Ltd
TEZACKI PUT BB, 21000 SPLIT, CROATIA, EUROPE TEL: ++385 21 374 510 FAX: ++385 21 374 111 E-MAIL: contact@solar-cells.net Solar cells links:
